| Camera |
| Image Sensor |
1/2.8? 2Megapixel progressive scan CMOS |
| Effective Pixels |
1920(H) x 1080(V) |
| RAM/ROM |
256MB/32MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/100000s |
| Minimum Illumination |
0.007Lux/F1.6( Color,1/3s,30IRE)0.06Lux/F1.6( Color,1/30s,30IRE)0Lux/F1.6(IR on) |
| S/N Ratio |
More than 50dB |
| IR Distance |
Distance up to 50m (164ft) |
| IR On/Off Control |
Auto/ Manual |
| IR LEDs |
1 |
| Lens |
| Lens Type |
Fixed |
| Mount Type |
Board-in |
| Focal Length |
2.8mm (3.6mm,6mm optional) |
| Max. Aperture |
F1.6 (F1.6, F1.6) |
| Angle of View |
H:110? (87?, 52?), V:58? (48?, 30?) |
| Optical Zoom |
N/A |
| Focus Control |
Fixed |
| Close Focus Distance |
0.9m(1.2m, 2.5m) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| 2.8 mm |
43m(141ft) |
17m(56ft) |
9m(30ft) |
4m(13ft) |
| 3.6 mm |
55m(180ft) |
22m(72ft) |
11m(36ft) |
6m(20ft) |
| 6.0 mm |
83m(289ft) |
33m(108ft) |
17m(56ft) |
8m(26ft) |
| Pan/Tilt/Rotation |
| Pan/Tilt/Rotation Range |
Pan:0?~360?; Tilt:0?~78?; Rotation:0?~360? |
| Intelligence |
| IVS |
Tripwire, Intrusion, Object Abandoned/Missing |
| Advanced Intelligent Functions |
Face Detection |
| Video |
| Compression |
H.265+/H.265/H.264+/H.264 |
| Streaming Capability |
3 Streams |
| Resolution |
1080P(1920×1080)/1.3M(1280×960)/720P(1280?720)/D1(704?576/704?480)/VGA(640?480)/CIF(352?288/352?240) |
| Frame Rate |
Main Stream: 1080P/720P(1~50/60fps) |
| Sub Stream: D1(1 ~50/60fps) |
| Third Stream: 1080P(1~25/30fps) |
| Bit Rate Control |
CBR/VBR |
| Bit Rate |
H.264: 24K ~ 10240KbpsH.265: 14K ~ 9984Kbps |
| Day/Night |
Auto(ICR) / Color / B/W |
| BLC Mode |
BLC / HLC / WDR(120dB) |
