| Camera | ||
|---|---|---|
| Image Sensor: | 1/3″ Progressive Scan CMOS | |
| Signal System: | PAL/NTSC | |
| Shutter time: | 1/25 s – 1/10,000 s | |
| Lens: | 2.8/4mm optional | |
| Lens Mount: | M12 | |
| Adjustment Range: | 2.8 mm: horizontal FOV 83°, vertical FOV 68° 4 mm: horizontal FOV 63°, vertical FOV 55° |
|
| Digital noise reduction: | 3D DNR | |
| Compression Standard | ||
|---|---|---|
| Video Compression: | H.264 | |
| H.264 code profile: | Baseline Profile/Main Profile | |
| Video bit rate: | 32Kbps~8Mbps | |
| Dual Stream: | Yes | |
| Image | ||
|---|---|---|
| Max. Image Resolution: | 640 × 960 | |
| Frame Rate: | Main stream: 50Hz: 25fps (640 × 480) 60Hz: 24fps (640 × 480) |
|
| Sub Stream: | 50Hz: 25fps (640 × 960) 60Hz: 24fps (640 × 960) |
|
| Image Settings: | Brightness is adjustable by client software or web browser | |
| 3D DNR: | Support | |
| Network | ||
|---|---|---|
| Alarm Trigger: | Motion detection, tampering alarm, HDD full, HDD error, network disconnected, IP address conflicted, illegal login | |
| Protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour | |
| General Function: | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering |
|
| System Compatibility: | ONVIF (Profile S, Profile G),ISAPI | |
| Intelligent | ||
|---|---|---|
| People Counting: | Support separate counting of people entering, exiting, and passing by | |
| Interface | ||
|---|---|---|
| Communication Interface: | 1 RJ45 10M/100M self-adaptive Ethernet port, 1 RS-485 interface | |
| Alarm: | 2 inputs, 1 output (up to 24 VDC 1 A, or 110 VAC 500 mA) | |
| Reset Button: | Yes | |
| General | ||
|---|---|---|
| IR Range: | Up to 5m | |
| Operation Condition: | -30°C to +60°C (-22 °F to +140 °F), Humidity 95% or less (non-condensing) | |
| Power Supply: | 12 VDC ± 25%, PoE (802.3af Class3) | |
| Power Consumption: | 12 VDC, max. 7 W, 0.6A PoE(802.3af, 36 V to 57 V), max. 7 W, 0.2 A to 0.13 A |
|
| Weather Proof: | -V: IP66 | |
| Dimensions: | Camera: 226 × 88 × 64 mm (8.88″ × 3.48″ × 2.50″) Package: 260 × 125 × 125 mm (10.24″ × 4.92″ × 4.92″) |
|
| Weight: | Approx.850 g (1.87 lb.), 1050 g (2.31 lb.) with package | |
