Audio Video Output
| HDMI Output | 2 |
|---|---|
| VGA Output | 1 |
| Video Output for 4K | 2x HDMI |
| Audio Output | 1-ch, RCA (2.0Vp-p , 1Kohm ) |
Hard Disk
| Optional discs | 2x SATA 6Gbps |
|---|---|
| HD Capacity | 10TB Pro HDD |
| HD form | 3.5” |
| Integrated drive | Without |
RAID
| RAID Type | No |
|---|
External Interface
| Network Interface | 2 x RJ-45 10/100/1000 Mbps Ethernet |
|---|---|
| USB Interface | 1 x USB Rear Pannel, 2 x USB Front Pannel |
| Bluetooth | No |
Specifications
| Power consumption (W) | 30 |
|---|---|
| Power supply | 230VAC |
| Signal System | HDMI, HDMI 4K, IP, VGA |
Environmental
| Chassis | 1U |
|---|---|
| Weight (g) | 3000 |
| Redundant Power Supply | No |
| 19″ Rack mounting | Yes |
| Working Temperature (°C) | From 0 to 45 |
| Housing width [mm] (H x W x D) (mm) | 45 x 445 x 290 |
Network
| Total LAN ports | 2 |
|---|---|
| Number of PoE ports | 0 |
Mainboard
| CPU | Celeron J3455 |
|---|---|
| RAM technology | DDR3 |
| RAM Slots | 1 |
| Memory installed | 4 |
| Memory max | 4 |
| CPU slots | 1 |
| CPU Cores | 4 |
| CPU Frequency | 2300 |
| GPU | Intel HD graphics 500 |
| Operating system | Win10 IoT Ent LTSB 2016 Entry EPKEA 64b |
| video analysis capability (Symphony VE130, multistream) | 8 |
| video display capability (multistream) | 8 |
| Video analysis and display | 6 |
Video Audio Input
| Audio Input | 1 |
|---|---|
| Audio in | 1 x jack |
Wifi
| WiFi | none |
|---|
