| System |
| Main Processor |
Dual-core embedded processor |
| Operating System |
Embedded LINUX |
| Audio and Video |
| IP Camera Input |
4 Channel |
| Two-way Talk |
1 Channel Input, 1 Channel Output, RCA |
| Display |
| Interface |
1 HDMI, 1 VGA |
| Resolution |
1920?1080, 1280?1024, 1280?720, 1024?768 |
| Multi-screen?Display |
1/4 |
| OSD |
Camera title, Time, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
H.264+/H.264 |
| Resolution |
6Mp/5Mp/4Mp/3Mp/1080P/ 720P/ D1&etc. |
| Record Rate |
80Mbps |
| Bit Rate |
16Kbps ~ 20Mbps Per Channel |
| Record Mode |
Manual, Schedule(Regular(Continuous), MD, Stop |
| Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection and Alarm |
| Trigger Events |
Recording, PTZ, Tour, Video Push, Snapshot, and Screen Tips |
| Video Detection |
Motion Detection, MD Zones: 396 (22 ? 18),and Tampering |
| Alarm input |
N/A |
| Relay Output |
N/A |
| Playback and Backup |
| Sync Playback |
1/4 |
| Search Mode |
Time /Date, MD and Exact Search(accurate to second) |
| Playback Function |
Play, Pause, Stop, Rewind, Fast play, Slow Play, Next File, Previous File, Next Camera, Previous Camera, Full Screen, Repeat, Shuffle, Backup Selection, Digital Zoom |
| Backup Mode |
USB Device/Network |
